B. O. D Incubator
Interior Polished stainless steel/Anodized aluminium
exterior finished in durable powder coated paints.
Control by wet & Dry bulb Micro controller / Direct Rh controller with dual display.
Circuit incorporated with solid state relays.
Adiustable time delay relay for safety of compressor.
B. O. D Incubator
Interior Polished Stainless Steel/Anodized aluminium and outer finished in durable powder coating paint. Precisely controlled by Microprocessor controller with dual display. Circuit incorporated with solid state relays. Adjustable time delay relay for safety of compressor and accurate performance. Study S. S. Trays, Precisely Fabricated to give rninium resistance to air Circulation.
APPLICATION
B.O.D INCUBATOR is multi-purpose Low Temperature Incubator, desiged with state-of-the-art technology to meet requirements for incubation of Bio chemical oxygen demand on water and sewage, study of enzymatic digestion process for studying tissue culture. Cell cloning, Microbiology, Bio-Chemistry, Agricultural, Medical, Pharmaceutical field etc.| Technical Specification | |
| Temperature Range | 5°C to 60°C |
| Accuracy | +1.0°C |
| Uniformity | +2.0°C |
| Control System | PLC or PID Based |
Construcation
| Working volume | 3, 6, 10, 12, 15, 18, 20, 22, 35, cu. ft. |
| Exterior | Heavy Guage - Mild Steel. |
| Interior | Polished Stainless / Anodized Aluminium |
| Chamber | Trippled Walled. |
| Mobility | On Castor Wheel. |
| Insulation | SuperiorThermofiber board / PUF Insulation. |
| Inner Door | Full view glass with metal frame. |
| Outer Door | With Lock and key/Mouled PVC Magnetic Gasket. |
| Shelves | Sturdy, Elegent-precisely fabricated to give minimum resistance to air circulation. |
| Finish | With attractive and durable powder coated paint in pleasant shed. |
| Circulation | Forced air circulation for uniform temperature by suction blower with Fan |
| Front panel | Mains rocker switch, Cooling / Heating rocker switch, Microcontroller Toggle switches for high and low position ofheaters, Fues. |
| illumination | With the opening of the door |
DISCRIPTION
→ Circulation : Forced Air by suction blower with Fan
→ Front Panel : Mains Rocker Switch, Cooling/Heating Rocker Switch, Micro Temp, Controller, Volt meter Ampere Meter, Fuse etc..
→ Illumination : With the opening of the door
HEATING
→ Tubular finned type air heater
REFRIGERATION
→ Compressor : Hermetically sealed of Kirloskar/Tecumseh make or equivalent
